سلسلة بوابات الدوران البصرية TC-3501

LOTC TC-3501 Optical Swing Turnstile Series offers premium access control solutions available in both single-lane (TC-3501S) and dual-lane (TC-3501D) configurations. Featuring elegant 304 stainless steel framework with transparent plexiglass arms, these turnstiles provide efficient traffic management with a flow rate of 40 people per minute per lane. The series seamlessly…

واتساب

LOTC TC-3501 Optical Swing Turnstile Series represents a premium line of access control solutions designed to combine sophisticated security with elegant aesthetics. Available in both single-lane (TC-3501S) and dual-lane (TC-3501D) configurations, this versatile series provides efficient pedestrian management while enhancing the visual appeal of entrance areas in various facilities.

التصميم والبناء

The TC-3501 series features a robust framework constructed from high-quality 304 stainless steel, complemented by transparent plexiglass swing arms and full glass side panels. This combination creates a modern, unobtrusive appearance that integrates seamlessly with contemporary architectural designs. The standard dimensions of 1200 × 200 × 980mm per lane make it suitable for installation in various spaces, with the single-lane model weighing 60kg and the dual-lane model weighing 70kg to ensure stability during operation.

Configuration Options

The TC-3501 series offers flexible configuration options to meet diverse security requirements:

TC-3501S (Single Core): Ideal for standard access points with single or bi-directional passage control, perfect for smaller entrances or facilities with moderate traffic flow.
TC-3501D (Double Core): Designed for high-traffic areas requiring simultaneous bi-directional passage management, making it ideal for main entrances, lobbies, and areas with significant pedestrian volume.

Access Control Capabilities

Both models in the TC-3501 series support integration with virtually any third-party access control technology, including:

Card readers (proximity, smart card, magnetic)
QR and barcode scanning systems
Biometric authentication (fingerprint, facial recognition, palm vein)
Remote control systems
Touchless button activation

This versatility allows the turnstiles to be incorporated into existing security ecosystems or serve as the foundation for new access control implementations.

مواصفات الأداء

The TC-3501 series delivers impressive performance with a standard flow rate of 40 people per minute per lane, making it suitable for medium to high-traffic environments. Both models feature a Mean Cycles Before Failure (MCBF) rating of 10 million operations, demonstrating exceptional durability and reliability for long-term use.

Technical Features

Operating voltage: 24V DC
Power consumption: 40W
Power supply: AC220V/110V, 50/60Hz
Operating temperature range: -20°C to 75°C
Operating humidity: 0 to 95% (non-condensing)
Passage width: 600-800mm standard (900mm optional for accessibility compliance)
LED indicators: Dual-color system (green for entry permission, red for no entry)
Infrared sensors: 4 pairs for precise detection and safety
Emergency function: Automatic arm opening during power outages
Communication interfaces: Dry contact, relay signal, RS485

Safety and Security

The TC-3501 series incorporates multiple safety features, including infrared sensors that detect obstacles and prevent the arms from closing on users. The automatic arm-opening function during power failures ensures safe evacuation in emergency situations. The system’s sophisticated detection capabilities minimize false alarms while maintaining high security standards.

Installation and Environment

Designed for versatility, the TC-3501 series is suitable for both indoor and sheltered outdoor installations. Its elegant design makes it appropriate for various settings, including:

Corporate office buildings
Government facilities
Financial institutions
Educational campuses
Healthcare facilities
Transportation hubs
Recreational and entertainment venues

Integration and Customization

The turnstile’s flexible architecture allows for seamless integration with existing security systems and building management platforms. Its communication interfaces support various protocols, enabling straightforward connection to centralized control systems for comprehensive security management.

Choosing Between Models

When selecting between the TC-3501S and TC-3501D models, consider:

Traffic Volume: For higher traffic areas, the TC-3501D provides more efficient people flow management with its dual-lane configuration.
Space Constraints: The TC-3501S offers a more compact footprint for installations with limited space.
Directional Requirements: While both models support bi-directional passage, the TC-3501D is optimized for simultaneous entry and exit traffic.

Budget Considerations: The TC-3501S provides a cost-effective solution for locations with moderate security requirements, while the TC-3501D offers enhanced capabilities for more demanding environments.

Technical Specifications for LOTC TC-3501 Optical Swing Turnstile Series

Model Information

Specification	Details
Model No.	TC-3501
يكتب	Optical Swing Turnstile Gate
ماركة	LOTC
Available Configurations	TC-3501S (Single Core), TC-3501D (Double Core)

المواصفات المادية

Specification	Details
Framework Material	304 Stainless Steel + Plexiglas Arm + Full Glass on side
Arm Material	Plexiglas transparency
Dimension	Standard: 1200 × 200 × 980mm per lane
الوزن الصافي	TC-3501S: 60kg/pcs (single core)<br>TC-3501D: 70kg/pcs (double core)
Passage Width	600-800mm (standard), 900mm (optional)
Passing Direction	Single directional / Bi-directional (both models)

مواصفات الأداء

Specification	Details
MCBF (Mean Cycles Before Failure)	10 million
Flow Rate	40 people per minute per lane

Electrical Specifications

Specification	Details
مزود الطاقة	AC220V/110V, 50/60Hz
Operation Voltage	24V DC
استهلاك الطاقة	40W

Environmental Specifications

Specification	Details
Operation Temperature	-20 °C ~ 75 °C
Operation Humidity	0 ~ 95% (No freeze)
Working Environment	Indoor / Outdoor (shelter)

Features and Functions

Specification	Details
LED Indicator	Two LED indicators on top: green → entry, red × no entry
Infrared Sensor	4 pairs
Emergency	Automatic arm open when power off
تواصل	Dry contact, Relay signal, RS485
Flexibility	Integrate with any access control

Access Control Options

Access Method	Availability
Card Solution	Yes
QR/Bar Code Solution	Yes
Biometric Solution	Yes
Remote Control	Yes
Touchless Button	Yes
Fingerprint	Yes
Face Recognition	Yes
Palm Vein	Yes

Model Comparison

Feature	TC-3501S (Single Core)	TC-3501D (Double Core)
Configuration	Single lane	Dual lane
وزن	60kg	70kg
Best For	Standard access points with moderate traffic	High-traffic areas requiring simultaneous bi-directional flow
Space Requirements	More compact footprint	Requires more installation space
Typical Applications	Secondary entrances, smaller facilities, office suites	Main lobbies, primary entrances, transportation hubs
Cost Efficiency	More economical for single-point access	Better value for high-volume traffic management

Installation Considerations

Both TC-3501S and TC-3501D models share the same installation requirements and integration capabilities. The choice between models should be based primarily on traffic volume, space availability, and specific security requirements rather than technical limitations.
